XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse Replaces WP8573713
XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse Replaces WP8573713
The XPARTCO 8573713 is an aftermarket replacement thermal cut-off fuse for Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers. This fuse is mounted on top of the burner funnel, directly under the drum, and it's a one-time safety device: as long as the dryer stays within its normal operating temperature, it does nothing at all, but the instant temperatures near the burner climb high enough — almost always from restricted airflow — the fuse permanently opens the circuit and cuts power. That's why a blown fuse produces such a specific symptom: the dryer won't heat, even though the drum may still tumble and the rest of the dryer seems to run normally.
Because this fuse sits on the burner funnel underneath the drum rather than on the more accessible blower housing, replacing it is a more involved repair than a typical thermal fuse swap — the drum has to come out of the cabinet to reach it. Unlike a resettable thermostat, this fuse cannot be reset once it blows; it must be replaced. A blown thermal fuse is almost always a symptom rather than a random failure: restricted exhaust venting is the leading cause, since trapped heat near the burner is exactly what this fuse is designed to react to. It directly replaces WP8573713, AP6013467, and PS11746693.
Quick Answer
The XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse fixes Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers that won't heat, even if the drum still tumbles normally. Mounted on the burner funnel under the drum. Replaces WP8573713, AP6013467, PS11746693. Always inspect and clean the dryer venting when replacing this fuse — a blown fuse is a symptom of restricted airflow, and installing a new fuse without fixing the vent will likely blow it again.
Common Problems This Part Fixes
- Dryer runs and tumbles but produces no heat
- Dryer that stopped heating suddenly, especially after running unusually hot
- Drying times that have gotten noticeably longer or clothes coming out damp
- Repeated blown fuses on a dryer with a known venting or airflow restriction
- Dryer that recently smelled like burning or overheating before losing heat
- Continuity test shows an open circuit across the old fuse
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This gas dryer thermal cut-off fuse directly replaces the following OEM and cross-reference part numbers:
WP8573713, 1180872, 8573713, AP3866211, EAP990558, PS990558, AWP49233, PD00006618
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This thermal cut-off fuse is compatible with select Whirlpool gas dryers, and also fits select Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, and Sears Canada gas dryers built on the Whirlpool platform, including model numbers such as WGD8500SR0, and Kenmore 11070372710 and 11071112020.
Note: This fuse is specific to gas dryers, mounted on the burner funnel. It is not the same fuse used on electric dryer platforms. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
- Aftermarket replacement thermal cut-off fuse — one-time safety device that cuts power if the dryer overheats
- Mounted on top of the burner funnel, directly under the drum
- Resolves "runs but won't heat," "drying takes too long," and "clothes coming out damp" symptoms caused by a blown fuse
- Replaces WP8573713, AP6013467, and PS11746693
- Compatible with Whirlpool, Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, and Sears Canada gas dryers
- Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
| Part Number | 8573713 |
| OEM Part Number | WP8573713 |
| Part Type | Gas Dryer Thermal Cut-Off Fuse |
| Condition | Aftermarket Replacement |
| Application | Gas Dryers |
| Location | Top of the burner funnel, under the drum |
| Resettable | No — one-time use, must be replaced once blown |
| Material | Plastic housing |
| Dimensions | Approx. 1"H x 1"W |
| Repair Difficulty | Moderate to Hard — drum removal required for access |
| Quantity | 1 thermal cut-off fuse |
| Compatible Brands | Whirlpool, Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, Sears Canada |
Installation Notes
Frequently Asked Questions
My dryer tumbles fine but there's no heat. Is this the right part?
Yes, this is the classic symptom of a blown gas dryer thermal cut-off fuse. Because this fuse only interrupts the heating circuit and not the drive motor, the drum can continue tumbling completely normally while the dryer produces no heat at all. If you've confirmed the burner isn't igniting and the fuse tests as an open circuit, this is very likely the fix.
Why does this repair require removing the drum? My other dryer's fuse didn't need that.
This particular fuse is mounted on the burner funnel underneath the drum rather than on the blower housing at the back of the cabinet, which is where many thermal fuses on other platforms are located. Reaching the burner funnel requires taking the drum out of the cabinet, which is why this repair involves more disassembly than some other thermal fuse replacements.
I replaced the fuse and it blew again. What's going on?
This is a strong sign that the underlying cause — almost always restricted airflow — was never addressed. Thermal fuses don't fail from age; they blow because the dryer overheated. If a new fuse keeps blowing, thoroughly inspect and clean the entire exhaust path from the lint trap housing to the outside vent hood, checking for lint buildup, crushed or kinked ductwork, or a vent run that's too long.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications and mounting configuration of the original WP8573713 thermal cut-off fuse used in compatible Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers.
