XPARTCO WD21X10519 Dishwasher Flood Switch

XPARTCO WD21X10519 Dishwasher Flood Switch – Compatible with GE, Hotpoint, and RCA Dishwashers

Product Description

Prevent overfilling and protect your dishwasher from water damage with the XPARTCO WD21X10519 Dishwasher Flood Switch. This Flood Switch Assembly is a replacement part compatible with GE dishwashers. The dishwasher flood switch and thermistor assembly is responsible for detecting and preventing water from overflowing the dishwasher. It is located at the base of the tub and detects when water is present in the base from a leak, preventing the water inlet valve from filling further. The thermistor shuts off the water flow from the valve if the incoming water temperature is outside of the acceptable range.

Replaces Part Numbers

WD21X10519, 3028650, WD21X10492, WD21X20204, PD00023214, EAP8690623, AP5781465, PS8690623.

Compatibility

This replacement flood  switch fits select GE, Hotpoint, and RCA dishwashers.

Example compatible models include (but are not limited to): GE GSD2100V65BB, GDF520PGJ2WW, Hotpoint HDA3600H35BB, and RCA RBD3300G00BB.

Always verify your dishwasher’s model number before ordering. Contact our support team if you’re unsure.

✅ Key Features

• 🔄 Aftermarket Replacement – Designed to meet OEM performance and safety standards

• 💧 Prevents Overfilling – Accurately detects water level and stops excessive filling

• 💰 Budget-Friendly Alternative – Provides OEM-like reliability at a lower cost

• 🛠️ Quick & Easy Installation – Simple wiring connection for fast repair

• 🛡️ Fixes Common Issues – Solves leaking, overfilling, or dishwasher not filling problems

📐 Product Specification

• Part Number: WD21X10519

• Component Type: Dishwasher flood Switch

• Material: Plastic flood housing with integrated electrical microswitch

• Mounting: Direct-fit installation beneath dishwasher tub

• Function: Monitors water level and signals control board

• Compliance: Built to OEM-equivalent quality standards (not OEM)

🛠️ Installation Notes

Tools Needed: Phillips screwdriver, pliers (optional)

⚠️ Safety First: Always unplug the dishwasher or turn off its circuit breaker before servicing.

Steps:

1. Disconnect power to the dishwasher.

2. Remove the toe-kick panel to access the flood  switch area.

3. Disconnect the wiring connector from the old switch.

4. Twist or unclip the old flood switch and remove it.

5. Install the new XPARTCO WD21X10519 switch in the same position.

6. Reconnect wiring, reinstall toe-kick panel, and restore power.

7. Run a quick fill test to confirm proper operation.

⏱️ Time Required: 10–15 minutes

📦 Shop With Confidence

• 🚚 Free Shipping on All Orders

• ⚙️ Trusted Appliance Parts Supplier

• 🔄 30-Day Return Policy

Protect your dishwasher from overfilling — Add to Cart Now for a reliable, cost-effective repair!
